HFP50000 Series Auger Drive – Excavators 20–50 Tonnes (110mm Square Hub)
High-Torque Hydraulic Auger Drive for Large Excavators
The HFP50000 Series Auger Drive is engineered for heavy-duty applications, compatible with excavators ranging from 20 to 50 tonnes. This robust auger drive is ideal for tasks such as deep drilling, fence piling, and large-scale landscaping projects. Built with high-quality EN series gear steel and the latest processing technology, it delivers durability, precision, and reliable performance.
⚠️ Quick connects to the machine are not included. Please contact us for information on compatible teeth and auger drill suitability.
✅ Key Features & Benefits
- Wide Machine Compatibility: Suits excavators from 20 to 50 tonnes, including cranes, skid steer loaders, and backhoe loaders.
- High Torque Output: Delivers maximum torque of 50,000 Nm, suitable for deep and large-diameter drilling.
- Versatile Drilling: Capable of drilling diameters from 100mm to 1,200mm and depths up to 30 meters.
- Durable Construction: High-quality materials to withstand demanding tasks.
- Forged Hood Ears: Standard in areas that experience significant strain, with all hood pins locked for extra safety.
- Optional 2-Way Valve: Converts a single-acting hammer circuit into a 2-way auxiliary flow, enhancing versatility.
⚙️ Specifications
| Specification | Value |
|---|---|
| Suitable for Excavators | 20–50 tonnes |
| Max Output Torque | 50,000 Nm |
| Drilling Diameter | 100mm – 1,200mm |
| Drilling Depth | Up to 30 meters |
| Pressure | 220–350 bar |
| Oil Flow | 100–300 LPM |
| Output Shaft Speed | 0–30 RPM |
| Hydraulic Hose | 1” BSP or 1¼” BSP |
| Output Shaft Size | 110mm Square |
| Weight | Approximately 460 kg |
| Overall Length | 1,354 mm |
📦 Package Includes
- HFP50000 Series Auger Drive
- Fittings and hoses
- Operator’s manual
🔖 Please provide your machine make, model & pickup specifications at checkout.
🛡️ Warranty & Support
- 12-Month Manufacturer’s Warranty
- Lifetime After-Sales Support
