Heavy Duty Hydraulic Rock Breaker 135mm Tool – $34,990 inc GST | 25 to 30 Ton Excavators with 100mm Pins
Industrial Grade Hydraulic Rock Breaker for Heavy Excavator Applications
$34,990 including GST.
The HFP1350 Hydraulic Rock Breaker is engineered for 25 to 30 tonne excavators requiring maximum breaking performance for rock breaking, concrete demolition, trenching, quarry work, mining support, demolition support and major civil construction applications.
Featuring a silenced enclosed housing, high-efficiency hydraulic circuit design and automatic self-greasing system supplied as standard, this breaker delivers powerful, repeatable impact energy while reducing daily maintenance requirements and helping maximise tool and bush life.
Designed specifically for heavy excavators, the substantial operating weight provides excellent machine stability while delivering dependable impact performance across demanding infrastructure, quarry, demolition and construction projects.
Built for Australian conditions, this breaker is ideally suited to contractors, hire fleets, councils, utilities, quarry operators and infrastructure contractors requiring a durable and serviceable hydraulic breaker for continuous heavy-duty use.
Key Features
• Automatic self-greasing system included as standard
• Silenced type enclosed housing
• 135mm chisel diameter
• Designed for 25 to 30 tonne excavators
• High-efficiency hydraulic oil circuit system
• Balanced operating weight for improved machine stability
• Simplified internal structure for easier servicing
• Reduced airborne noise compared to open type designs
• Four chisel tools supplied
• Hydraulic hoses and fittings included
Suitability
Designed for 25 to 30 tonne excavators operating with 130 to 150 L/min hydraulic flow.
Suitable for excavators fitted with 100mm pin pickups.
Commonly used by contractors, councils, utilities, hire fleets, quarry operators and infrastructure contractors for rock breaking, concrete demolition, quarry operations, trenching, roadworks, civil construction, demolition support and excavation support works.
Specifications
| Specification | HFP1350 Rock Breaker |
|---|---|
| Carrier Weight Range | 25–30 Ton |
| Body Weight Including Chisel | 850 kg |
| Total Operating Weight | 1898 kg |
| Overall Dimensions | 2847 × 560 × 710 mm |
| Hydraulic Oil Flow | 130–150 L/min |
| Hydraulic Pressure | 160–180 kg/cm² |
| Blow Frequency | 400–800 BPM |
| Chisel Diameter | 135 mm |
| Housing Type | Silenced Type |
| Lubrication System | Automatic Self Greasing |
Package Includes
• HFP1350 hydraulic rock breaker
• Automatic self-greasing system
• 1 x Blunt Chisel
• 1 x Conical Chisel
• 1 x Wedge Chisel
• 1 x Moil Point Chisel
• Hydraulic hoses and fittings
• 12 month manufacturer warranty
• HFP technical support
Machine side quick connects are not included.
Why Choose HFP Attachments
Most suppliers just import and move boxes — then you're on your own. HFP is different.
• Imported and Australian-made attachments available
• Expert advice from purchase through to installation
• Local warranty, repairs, and technical support
• Experienced team who understand fitment and real-world applications
With HFP, you get the right attachment, correctly fitted, and backed by local support.
Support & Warranty
The HFP1350 Hydraulic Rock Breaker is backed by a 12 month manufacturer warranty and supported locally by HFP Attachments.
Support includes:
• Manufacturer warranty support
• Spare parts availability
• Technical support
• Product selection assistance
• Hose and fitment support
• After sales support
• Local service support
Important Information
To ensure correct supply, please provide:
• Machine Make
• Machine Model
• Pin Diameter
• Pin Centre to Pin Centre
• Width Between Ears
• Quick Hitch Type
Hydraulic hoses and fittings are included.
Machine side quick connects are not included.
Automatic self-greasing system is included as standard.
Machine details must be provided at checkout or emailed after ordering to ensure correct pickup configuration.
Product specifications, pickup configuration and hose setup may vary depending on machine requirements.
Fleet colour availability may be available on request for councils, utilities, hire fleets and government orders.
Freight & Delivery
Delivery is typically arranged to:
• Your nearest freight depot, or
• A commercial business with forklift facilities
Please note any property with a house is classified as residential by freight carriers and may incur additional delivery charges. Contact us with your suburb and postcode for an accurate freight quote.
Fitment & Bucket Class Information
This breaker is designed for 25 to 30 tonne excavators fitted with 100mm pin pickups.
Machine pickup dimensions can vary between manufacturers and models. To ensure correct fitment, confirmation of pin diameter, pin centres, ear width and quick hitch type is required prior to ordering.
Machine side quick connects are not included and may vary depending on machine manufacturer and coupler style.
Correct hydraulic flow, pressure, mounting configuration and machine stability are critical for safe and reliable breaker operation.
